231-354/001-000 WAGO Connectors, Interconnects distributor and supplier

Same model may have multiple batches, images only for reference.

231-354/001-000
Manufacturer No:	231-354/001-000
Manufacturer:	WAGO
SUVSysrem No:	231-354/001-000
Package:	Box
Datasheet:	231-354/001-000
Description:	24 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.200" (5.08mm) Vertical Through Hole
Request Free Samples

ESD
ISO9001
ISO13485
ISO14001
ISO45001

231-354/001-000 information

Product Attributes	Attribute Value
Category	Connectors, Interconnects
Manufacturer	WAGO
Package	Box
Description	24 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.200" (5.08mm) Vertical Through Hole
Color	Orange
Mounting Type	Through Hole
Number of Positions	24
Pitch	0.200" (5.08mm)
Type	Header, Male Pins, Shrouded (4 Side)
Operating Temperature	-60°C ~ 100°C
Termination Style	Solder
Material Flammability Rating	UL94 V-0
Current - IEC	12A
Number of Levels	1
Positions Per Level	24
Contact Material	Electrolytic Copper
Header Orientation	Vertical
Housing Material	Polyamide (PA66), Nylon 6/6
Contact Mating Finish	Tin
Contact Tail Length	0.197" (5.00mm)
Insulation Height	0.472" (12.00mm)
Current - UL	10 A
Voltage - IEC	630 V
Voltage - UL	600 V
