2092-1174/000-5000 WAGO Connectors, Interconnects distributor and supplier

Same model may have multiple batches, images only for reference.

2092-1174/000-5000
Manufacturer No:	2092-1174/000-5000
Manufacturer:	WAGO
SUVSysrem No:	2092-1174/000-5000
Package:	Box
Datasheet:	2092-1174/000-5000
Description:	4 Position Terminal Block Header, Female Sockets 0.197" (5.00mm) Vertical Through Hole
Request Free Samples

ESD
ISO9001
ISO13485
ISO14001
ISO45001

2092-1174/000-5000 information

Product Attributes	Attribute Value
Category	Connectors, Interconnects
Manufacturer	WAGO
Package	Box
Description	4 Position Terminal Block Header, Female Sockets 0.197" (5.00mm) Vertical Through Hole
Features	Push Button Actuated
Color	Gray
Mounting Type	Through Hole
Number of Positions	4
Pitch	0.197" (5.00mm)
Type	Header, Female Sockets
Operating Temperature	-60°C ~ 100°C
Termination Style	Solder
Material Flammability Rating	UL94 V-0
Current - IEC	16A
Number of Levels	1
Wire Gauge or Range - AWG	12-24 AWG
Wire Gauge or Range - mm²	0.2-2.5mm²
Positions Per Level	4
Contact Material	Electrolytic Copper
Header Orientation	Vertical
Housing Material	Polyphthalamide (PPA), Glass Filled
Contact Mating Finish	Tin
Wire Strip Length	9-10mm
Contact Tail Length	0.142" (3.60mm)
Insulation Height	0.638" (16.20mm)
Current - UL	15 A
Voltage - IEC	630 V
Voltage - UL	300 V
