| Product Attributes |
Attribute Value |
| Category |
Integrated Circuits (ICs) |
| Manufacturer |
Texas Instruments |
| Package |
Tape & Reel (TR) |
| Description |
2 Circuit IC Switch 1:1 3.2Ohm 10-VSSOP |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| On-State Resistance (Max) | 3.2Ohm |
| -3db Bandwidth | 45MHz |
| Supplier Device Package | 10-VSSOP |
| Voltage - Supply, Single (V+) | 4.5V ~ 36V |
| Voltage - Supply, Dual (V±) | ±4.5V ~ 18V |
| Charge Injection | -13pC |
| Crosstalk | -93dB @ 1MHz |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ΔRon) | 100mOhm |
| Switch Time (Ton, Toff) (Max) | 180ns, 180ns |
| Channel Capacitance (CS(off), CD(off)) | 26pF, 35pF |
| Current - Leakage (IS(off)) (Max) | 250pA |
| Number of Circuits | 2 |
