| Product Attributes |
Attribute Value |
| Category |
RF and Wireless |
| Manufacturer |
Taoglas |
| Package |
Bulk |
| Description |
1.227GHz, 1.249GHz, 1.542GHz, 1.561GHz, 1.575GHz, 1.589GHz BeiDou, Galileo, GLONASS, GNSS, GPS Ceramic Patch RF Antenna 1.217GHz ~ 1.237GHz, 1.241GHz ~ 1.258GHz, 1.525GHz ~ 1.559GHz, 1.559GHz ~ 1.563GHz, 1.563GHz ~ 1.587GHz, 1.569GHz ~ 1.61GHz 3.05dBi, 2.86dBi, 4.33dBi, 4.48dBi, 4.5dBi, 2.46dBi IPEX MHFI (U.FL) Adhesive |
| Features | Cable - 100mm, LNA, Filter |
| Mounting Type | Adhesive |
| Frequency Range | 1.217GHz ~ 1.237GHz, 1.241GHz ~ 1.258GHz, 1.525GHz ~ 1.559GHz, 1.559GHz ~ 1.563GHz, 1.563GHz ~ 1.587GHz, 1.569GHz ~ 1.61GHz |
| Applications | BeiDou, Galileo, GLONASS, GNSS, GPS |
| Gain | 3.05dBi, 2.86dBi, 4.33dBi, 4.48dBi, 4.5dBi, 2.46dBi |
| Termination | IPEX MHFI (U.FL) |
| Number of Bands | 6 |
| VSWR | 2 |
| Antenna Type | Ceramic Patch |
| Height (Max) | 0.596" (15.15mm) |
| Frequency Group | UHF (1GHz ~ 2GHz) |
| Frequency (Center/Band) | 1.227GHz, 1.249GHz, 1.542GHz, 1.561GHz, 1.575GHz, 1.589GHz |
| RF Family/Standard | Navigation |
