| Product Attributes |
Attribute Value |
| Category |
Connectors, Interconnects |
| Manufacturer |
HARTING |
| Package |
Bulk |
| Description |
9 Position Terminal Block Plug, Female Sockets 0.197" (5.00mm) 180° Free Hanging (In-Line) |
| Features | Push Button Actuated, Retention Latches (Non-Wire Side) |
| Color | Green |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 9 |
| Pitch | 0.197" (5.00mm) |
| Type | Plug, Female Sockets |
| Operating Temperature | -40°C ~ 110°C |
| Termination Style | Screwless - Spring Cage, Tension Clamp |
| Material Flammability Rating | UL94 V-0 |
| Number of Levels | 1 |
| Wire Gauge or Range - AWG | 12-30 AWG |
| Wire Gauge or Range - mm² | 0.2-2.5mm² |
| Positions Per Level | 9 |
| Contact Material | Copper Alloy |
| Plug Wire Entry | 180° |
| Housing Material | Polyamide (PA), Nylon, Polyphthalamide (PPA) |
| Contact Mating Finish | Tin |
| Wire Strip Length | 10mm |
| Insulation Height | 0.587" (14.91mm) |
| Current - UL | 12 A |
| Voltage - UL | 300 V |
