| Product Attributes |
Attribute Value |
| Category |
Connectors, Interconnects |
| Manufacturer |
ASSMANN WSW Components |
| Package |
Tape & Reel (TR) |
| Description |
Connector Header Surface Mount, Right Angle 31 position 0.100" (2.54mm) |
| Features | Board Guide, Pick and Place |
| Connector Type | Header, Cuttable |
| Current Rating (Amps) | 3A |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 31 |
| Number of Rows | 1 |
| Style | Board to Board |
| Operating Temperature | -55°C ~ 105°C |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Brass |
| Insulation Color | Black |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | Flash |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Post | Flash |
| Contact Shape | Square |
| Insulation Height | 0.136" (3.46mm) |
| Shrouding | Unshrouded |
| Insulation Material | Polyamide (PA6T), Nylon 6T, Glass Filled |
| Contact Length - Mating | 0.230" (5.84mm) |
